3D Model-Based Process Control for the Future of Smart Manufacturing

Published by Coventor at July 14, 2017
Categories
  • Coventor Blog
Tags
  • Technology Reviews

David Fried, CTO of Coventor, gave a presentation entitled “3D Model-Based Process Control for the Future of Smart Manufacturing” at SEMICON West 2017. Listen to this presentation to gain an understanding of high-speed 3D process modeling and how model-based process control can be used to improve process yield of advanced semiconductor technologies.

Advanced CMOS and memory technologies are becoming more structurally complex at an amazing rate.  In Logic CMOS, just since 65nm, we have introduced embedded stressor source/drains, replacement high-k/metal-gates, FinFETs, complex multi-patterning schemes and many more structural innovations.  NAND Flash has moved from conventional planar bit-lines to amazing 3D vertical bit-lines.  DRAM continues (against all odds) to scale the bit-cell area, by burying the word-line, using amazingly high-aspect ratio capacitors and employing even more complex multi-patterning schemes.  In all of these innovations, the semiconductor industry has taken effectively “top-down processing capabilities” from the planar era, and applied them to 3D structures, using surfaces (ie, sidewalls) that were not previously employed in devices.  The next set of logic and memory innovations will certainly continue this trend, even employing the processes to use surfaces not-visible from top-down observation. Gate-All-Around (GAA) or Nanowire devices, for example, will have critical structural requirements underneath the device, representing a whole new paradigm of challenges both for metrology and process.  Process enhancements, such as Atomic Layer Deposition (ALD) and Atomic Layer Etching (ALE) will be required. Metrology improvements from Optical Critical Dimension (OCD) and X-Ray measurement techniques (XRD, XRR,etc.) will be required.  But the integrated complexity of these processes and patterning schemes will also drive a new era in advanced model-based process control that links the most advanced metrology and inspection results with the most advanced processes and equipment-level controls through feed-forward and feed-back control schemes.
