Condenser microphone model in Cadence Virtuoso biased under constant charge. Parasitic capacitance and leakage resistance loads the output. An A-weighting filter is included in order to compute the A-weighted SNR. The inset image shows Spectre simulated results, post processed to computed Sensitivity, SNR and THD
