45nm PMOS transistor after epitaxial SiGe growth. The resist (red) isolates PMOS devices during the SiGe process. The spacer is undercut slightly during the recess etch, producing a notch in the SiGe profile that is visible in the SEM and accurately modeled with SEMulator3D.
